Detalles
Transmisión de Poleas y Banda
| MODELO | CAUDAL | POTENCIA (HP) |
P. PÚBLICO M.N. |
|
| CFM | M3/HR | |||
| RUB-24/L | 4,592 | 7,802 | 1/2 | $ 44,355.00 |
| RUB-24/M | 5,510 | 9,362 | 1/2 | $ 46,318.00 |
| RUB-24/H | 6,428 | 10,921 | 3/4 | $ 48,243.00 |
| RUB-30/L | 7,547 | 12,823 | 1/2 | $ 49,577.00 |
| RUB-30/M | 8,675 | 14,739 | 3/4 | $ 53,502.00 |
| RUB-30/H | 9,765 | 16,591 | 3/4 | $ 59,535.00 |
| RUB-36/L | 10,971 | 18,640 | 3/4 | $ 61,650.00 |
| RUB-36/M | 12,726 | 21,621 | 3/4 | $ 62,879.00 |
| RUB-36/H | 14,628 | 24,853 | 1 | $ 65,817.00 |
| RUB-42/L | 14,555 | 24,729 | 3/4 | $ 68,943.00 |
| RUB-42/M | 17,446 | 29,641 | 1 | $ 74,212.00 |
| RUB-42/H | 20,237 | 34,383 | 1 1/2 | $ 78,727.00 |
| RUB-48/L | 21,735 | 36,928 | 1 | $ 87,245.00 |
| RUB-48/M | 23,968 | 40,722 | 1 1/2 | $ 91,769.00 |
| RUB-48/H | 27,802 | 47,236 | 2 | $ 97,039.00 |
| RUB-54/30° | 31,400 | 53,349 | 3 | $ 112,086.00 |
| RUB-54/36° | 38,300 | 65,072 | 5 | $ 119,136.00 |
| RUB-54/43° | 45,000 | 76,455 | 7.5 | $ 127,006.00 |
| RUB-54/48° | 48,900 | 83,081 | 10 | $ 132,506.00 |
| RUB-60/30° | 38,600 | 65,581 | 3 | $ 117,609.00 |
| RUB-60/36° | 47,500 | 80,702 | 5 | $ 125,006.00 |
| RUB-60/43° | 57,500 | 97,692 | 7.5 | $ 133,037.00 |
| RUB-60/48° | 63,000 | 107,037 | 10 | $ 138,951.00 |
NOTA: RUB-**/*-1 127-220V/1F/60Hz
RUB-**/*-3 440-220V/3F/60Hz
L: RPM Baja | M: RPM Media | H: RPM Alta
